KR500 Pure Epoxy

  • High bond strength with High load resistance.
  • Used with all grades of threaded rod and rebar in accordance with TR029.
  • Ideal for deep embedment installations.
  • ETA approved for seismic Loads C1 and C2.
  • ETA approved for rebar installations under TR023 and EN 1992-1-1:2004 EC2.
  • ETA approved for diamond drilled holes.
  • Used in non-cracked and cracked concrete.
  • Used in dry and wet concrete and also in wood.
  • Used in flooded holes.
  • Used for overhead applications.
  • Used for elevated temperatures temperature ranges I, II and III.
  • Zero shrinkage enables large diameter installations.
  • Manual cleaning up to 20 mm diameter and embedment depths of 240 mm.
  • This product should be stored between +5o °C & + 25o °C.
  • The Shelf life of the product is 24 months from the manufacture data.
  • Static and quasi-static loads: M8 to M30, Rebar Ø 8 to Ø 32.
  • Use in indoor and outdoor environments.
  • Structural applications.
  • Fixing of building substructures.
  • Rebar and start rebar.
  • Safety barriers, billboards, heavy engine, etc.
  • Large metric sizes, retaining walls.
  • Independently tested and approved anchor life 50 years.

Category:
CodePacking
KR 385 EPX385 ml
KR 585 EPX585 ml
KR 1400 EPX1400 ml

Minimum Curing Time

Base material temperature [°C ]Gel time (working time)Minimum curing time in dry concreteMinimum curing time
in wet concrete
+5 to +9120 min50 h 100 h
+10 to +1990 min 30 h 60 h
+20 to + 2930 min10 h 20 h
+30 to + 3920 min6 h 12 h
+4012 min4 h 8 h
